Metal detector for needles

For inspection of block meat, such as beef and pork.

Metal detector for needles
For inspection of block meat, such as beef and pork.

Even magnetized needles used for baby pigs whichcannot be detected conventionally can be detected accurately.
*Conveyor belt easy attach and remove system is option.

Specifications

D (non-waterproof) / W (waterproof)

Model SD3P-XXXXVW
4505 6517P 9617P 11825P
Maximum passage width(mm) 325 485 770 980
Maximum passage height(mm) 50 170 170 250
Detection sensitivity(mm)Fe φ0.6 φ1.2 φ1.8 φ2.0
Conveyor speed 24m/min (50Hz)
Conveyor size(mm) Belt width 200 350 500 700
Length 1800 2200 2600 2800
Upon detection of metal Belt stopped, buzzer warning or automatic sorting (option)
Weight capacity(kg) 20 30 30 30
Operating environment Temperature: 0 to 40℃, Humidity: 30 to 75%, No dew condensation allowed.
Main power supply AC100V±10%,
50 / 60Hz, 450VA
Three-phase AC200V±10%, 50 / 60Hz, 700VA
Coil type Concentric loop coil Opposed coil
Weight(kg) 210 300 380 500

The detection sensitivity represent the values when only a test piece is fed over the belt surface.
The detection sensitivity depends on the product and/or operating environment.
Please make sure that something such as products are not going to hit the inside of the aperture.
The specifications are subject to change without prior notice due to improvement.

Appearance figure
