SD3-45 Type

For inspection of products packed in larger trays

SD3-45 Type
For inspection of products packed in larger trays

specifications

D (non-waterproof) / W (waterproof)

Model SD3-4508D/W SD3-4510D/W SD3-4512D/W SD3-4515D/W SD3-4518D/W
Maximum passage width 450mm
Maximum passage height 80mm 100mm 120mm 150mm 180mm
Detection
sensitivity		 Fe φ0.45mm φ0.5mm φ0.55mm φ0.6mm φ0.7mm
SUS304 φ0.8mm φ0.9mm φ1.0mm φ1.1mm φ1.2mm
Belt speed 24m/min (50Hz)
Conveyor size 800mm (length)×350mm (belt width)
Upon detection of metal Belt stopped, buzzer warning, or automatic sorting (option)
Transport weight 3kg
Power requirements AC100V±10%、50/60Hz、200VA　or　AC200V±10%、50/60Hz、200VA
Mass 107kg 108kg 109kg 112kg 115kg

The values for detection sensitivity represent the values when only a test piece is fed over the belt surface.
Values may vary depending on the product being handled and operating environment.

appearance figure
